Description
The newest generation of the ECO Farm 315W CMH ballast was developed to optimize the output of the 315W CMH bulbs. Our lamp and ballast are tuned to work together at over 99% efficiency when operated together, you will receive less color shifts, lower lamp temperatures, and less frequency humming.
High-reliability digital driver circuit. Smart, high sensitivity anti-thunder, open circuit, short circuit, over-current, over-voltage, over-temperature protection technology.
|
MODEL |
315W CMH DIGITAL BALLAST |
| Technology | Digital |
| Rated Power | 315W |
| Lamp type: | 315W CMH LAMP |
| Rated Input Voltage | 220-240V AC |
| Voltage input range | 190Vac~265Vac |
| Input frequency | 50Hz~60Hz |
| Input Running Current | 1.5A |
| Ignition Voltage | 3.5~5kV |
| Required lamp voltage | 100~120V |
| Power factor | ＞0.99 |
| Efficiency | >95% |
| THD | ＜10% |
| Dimming | NO |
| Current crest factor | ＜1.6 |
| Output frequency | 120 Hz |
| Protection | Full circuit protection for Hot Start, Short Circuit , Opening Circuit, ignition failure, over/low voltage, overflow current,thermal,end of lamp life |
| Max. Lamp distance from ballast | 15m |
| Operating temperature range (ta) | -20℃~+50℃ |
| Ta | 40℃ |
| Tc | 70℃ |
| Case | Aluminium |
| Length of Input Power lead | 1.8 M |
| Length of Output Power lead | 0.2 M |
