Description
- ECO Farm 7 ton rosin press squished out considerably more concentrate and was way less exhausting than other brand. If you've got access to an abundance of high-quality flower and want to make solventless (and delicious!) extracts at home, it's a worthwhile option to consider.
- This ECO2042 rosin press machine can provide double-sided heating, manual high pressure, and automatic timing functions.
- Rosin press is the machine that use of temperature, pressure and a certain period of time to extract oil/squeeze rosin flowers and so on. This model is a hydraulic manual model with high pressure, high efficiency and good oil return rate.
- Do not put the power cord on the heating plate.
- Do not touch the heating plate when the power is on. Warning: Risk of burns.
- Do not open the inside of the machine and make changes to the equipment.
- Do not allow liquid or metal objects to enter the heat press machine.
- Make sure that the machine is connected to the other end of the power cord.
- Do not unplug the cable to disconnect the plug.
- Turn off the power of the machine and unplug it after use.
- Be careful when using the machine when there are children nearby.
- Ensure that the equipment is used in a safe environment.
|
7 ton manual rosin press
|
|
|
Power:
|
1100W/1200W
|
|
Platen Size:
|
6x12cm (2.3''x4.7'')
|
|
Pressure range:
|
0-7ton
|
|
Time set:
|
0-999s
|
|
Temp set:
|
0-200C/0-4000F
|
|
pressure adjustable range:
|
0-7ton
|
|
G.W:
|
20kg
|
1. Set temperature & time
(Blue represents temperature, white represents time)
2.1. Press the switch ON/OFF on the side of the heat press machine to make it work normally.
2.2. Press the "SET" key, and adjust the "▼" or "▲" up and down keys to obtain the desired temperature.
2.2. Press the "SET" button again, and adjust the "▼" or "▲" up and down keys to obtain the required time.
2.3. After finishing all the settings, press the "SET" button again and wait for the machine to heat up.
2.4. When the machine reaches the set temperature, put the product on the workbench and press down on the heating plate, and wait for the time to count down.
2.4. When the machine reaches the set temperature, put the product on the workbench and press down on the heating plate, and wait for the time to count down.
Cleaning and maintenance:
Different projects will require different temperature and time settings because the material or thickness is different.
This machine is not suitable for children's use or food processing.
When the machine is not in use, turn off the machine and unplug the power cord.
If the hot press is not used for more than 30 minutes, the hot plate will automatically cool to room temperature.
When the temperature of the hot plate reaches 80°C (176°F), the radiating fan will automatically start). It is beneficial to reduce the temperature of electrical parts and prolong their service life.
Different projects will require different temperature and time settings because the material or thickness is different.
This machine is not suitable for children's use or food processing.
When the machine is not in use, turn off the machine and unplug the power cord.
If the hot press is not used for more than 30 minutes, the hot plate will automatically cool to room temperature.
When the temperature of the hot plate reaches 80°C (176°F), the radiating fan will automatically start). It is beneficial to reduce the temperature of electrical parts and prolong their service life.
