Description
- EP1500 series inverter is with PWM wave and Rated Power from 300W to 3000W, designed to meet different requirements in the Middle Market. Power supply by converting DC 12V/24V/48V (For example, Batteries of Cars, Ships and accumulator etc.) to AC 220V, and suitable for electrical requirement less than 3000W (e.g. Cellphone, Laptop, and Solar Power System etc.)
- Design of aluminum case ensures its excellent cooling ability and sturdiness, also extending service life.
- Car cigarette lighter wire and clip wire (optional) for using in car or be used for battery.
- USB Interface (Optional); LED Lights for showing the working or protecting status; Button switch to control inverter.
- Can start up special load such as Refrigerator, Air-Condition, etc.
| Model | EP15-P300 | EP15-P500 | EP15-P1000 | EP15-P1000 | EP15-P2000 | EP15-P3000 | |
| Rated power | 300W | 500W | 1000W | 1500W | 2000W | 3000W | |
| Max power | 600W | 1000W | 2000W | 3000W | 4000W | 6000W | |
| Input voltage | 12Vdc | 12/24/48Vdc | 24/48Vdc | ||||
| Output voltage | 220Vac | ||||||
| Output wave form | PMW | ||||||
| Output frequency | 50/60Hz | ||||||
| USB Port | 5V 0.5/2A (optional) | ||||||
| Protections | Overload protection, short circuit protection, over temperature protection and battery anti reverse connection function. | ||||||
| Unit dimension (mm) | 120*100*50mm | 165*100*50mm | 402*241*93mm | ||||
| Environment of performance | Temperature 0℃~40℃,Humidity 20%~90% | ||||||
| Noise level | ≤40dB(1m) | ||||||
