Description
- EP2000 PRO series inverter is a cost effective, intelligent with UPS function. The comprehensive LCD offers user-configurable and easy-accessible button adjustment such as battery charge current, battery charge voltage, frequency, buzzer etc. It's perfect for the user who need a simple and economical inverter,with user-friendly installnation and setting.Tower and rack design available for different choices.
- Rated power 300W to 1000W
- Pure sine wave output
- Smart LCD setting ( frequency , charge voltage,charge current, etc)
- 3 steps charging algorithm
- Built in AVR function
- Overload and short-circuit protection
- Battery reverse polarity protection (Optional)
- Deep discharge protection
- Cold start function
| MODEL | EP20-0312 PRO | EP20-0612 PRO | EP20-0812 PRO | EP20-1012 PRO | EP20-0324 PRO | EP20-0624 PRO | EP20-0824 PRO | EP20-1024 PRO |
| Default Battery System Voltage | 12VDC | 24VDC | ||||||
| INVERTER OUTPUT | ||||||||
| Rated Power | 300W | 600W | 800W | 1000W | 300W | 600W | 800W | 1000W |
| Surge Rating | 900VA | 1800VA | 2400VA | 3000VA | 9000VA | 1800VA | 2400VA | 3000VA |
| Waveform | Pure sine wave | |||||||
| Rated Output Voltage | Inverter: 230VAC ±2% (RMS), AVR: 195VAC-245VAC | |||||||
| Output Frequency | 50Hz / 60Hz ±0.2Hz | |||||||
| Invertert Frequency (Peak) | >75% | >81% | ||||||
| Bypass Efficiency | >95% | |||||||
| Output Transfer Time | Typical:6ms 10ms(max) | |||||||
