Description
- EP3000 LV2 series is very economical pure sine wave inverter, special in north & south america market, and AC charger from 35A to 70A .Solar\AC priority configurable. When solar priority , in case its charge current lower than inverter’s charger from AC, AC will supplement to charge the batteries, to optimize charging. With low frequency transformer, it enable the inverter to operate with all kinds of home appliances.
- Pure sine wave output
- Friendly user interface
- 3 steps charging
- MFD (multi-function display)
- Overload and short-circuit protection
- Set charging voltage/charging current
- Battery low voltage shutdown point can be set to 10/10.5/11V
- Power-save mode
- Set utility priority/ Battery priority
- Set utility input wide/narrow range
- Inverter voltage can be set to 110V/115V/120V
- Inverter frequency can be set to 50/60Hz
- Set utility charging on/off switch
| MODEL | EP30-1KW LV2 | EP30-1.5KW LV2 | EP30-2KW LV2 | EP30-3KW LV2 | EP30-4KW LV2 | EP30-5KW LV2 | ||||||
| Nominal Battery System Voltage | 12VDC | 24VDC | 12VDC | 24VDC | 12VDC | 24VDC | 24VDC | 48VDC | 24VDC | 48VDC | 48VDC | 48VDC |
| INVERTER OUTPUT | ||||||||||||
| Reted Power | 1.0KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | |||||
| Surge Rating | 3000VA | 4500VA | 6000VA | 9000VA | 12000VA | 15000VA | 18000VA | |||||
| Capable Of Starting Electric Motor | 1HP | 2HP | 3HP | |||||||||
| Waveform | Pure sine wave/ same as input (bypass mode) | |||||||||||
| Nominal Output Voltage RMS | 110V/115V/120VAC ±10% (RMS) | |||||||||||
| Output Frequency | 50Hz/60Hz±0.3 Hz | |||||||||||
| Inverter Efficiency(Peak) | >88% | |||||||||||
| Line Mode Efficiency | >95% | |||||||||||
| Power Factor | 1 | |||||||||||
| Typical Transfer Time | 10ms(max) | |||||||||||
