Description
- EP3000 PLUS series is a very economical pure sine wave inverter, with AC charger from 20A to 60A; Solar/AC priority is configurable, when setting solar priority, solar will charge batteries as first priority, and AC can also charge batteries when solar charger current is too lower. With pure copper transformer, it enables inverter to operate with all kinds of home appliances.
- Pure sine wave output
- Friendly user interface
- 3 Steps charging
- MFD (multi-function display)
- Overload and short-circuit protection
- Set charging voltage/charging current.
- Battery low voltage shutdown point can be set to 10/10.5/11V
- Power-save mode
- Set utility priority/ Battery priority
- Set utility input wide/narrow range
- Inverter voltage can be set to 120V:110V/115V/120V ; 220V:220V/230V/240V
- Inverter frequency can be set to 50/60Hz
- Set utility charging on/off switch
| MODEL | EP30-1KW PLUS | EP30-1.5KW PLUS | EP30-2KW PLUS | EP30-3KW PLUS | EP30-4KW PLUS | EP30-5KW PLUS | EP30-6KW PLUS | ||||||
| Nominal Battery System Voltage | 12VDC | 24VDC | 12VDC | 24VDC | 12VDC | 24VDC | 24VDC | 48VDC | 24VDC | 48VDC | 48VDC | 48VDC | |
| INVERTER OUTPUT | |||||||||||||
| Rated Power | 1KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | ||||||
| Surge Rating | 3000VA | 4500VA | 6000VA | 9000VA | 12000VA | 15000VA | 18000VA | ||||||
| Capable Of Starting Electric Motor | 1HP | 1HP | 1HP | 2HP | 3HP | ||||||||
| Waveform | Pure sine wave / same as input (bypass mode) | ||||||||||||
| Nominal Output Voltage RMS | 220V / 230V / 240VAC ±10% (RMS) | ||||||||||||
| Output Frequency | 50Hz / 60Hz ±0.3Hz | ||||||||||||
| Inverter Efficiency (Peak) | >88% | ||||||||||||
| Line Mode Efficiency | >95% | ||||||||||||
| Power Factor | 1 | ||||||||||||
| Typical Transfer Time | 10ms(max) | ||||||||||||
