Description
- Low frequency pure sine wave combined inverter&A/C charger EP3000 PRO Series 8 -12kw; Quiet, high efficiency operation front panel LED+LCD indicators and adjustable switch selectors selectable settings for flooded lead acid, Gel, or absorbed glass mat(AGM) batteries. Mainly for home and office applicances such as TV, refrigerator, fans lights and computers etc.
- Pure sine wave output
- Max 140A automatic 3-stage battery charger
- Charger current is Adjustable (0-100%)
- Automatically send signal to start generator
- Supporting USB/RS485 communicaion and BTS & AGS port
- Battery/AC priority
| MODEL | EP30-8KW PRO | EP30-10KW PRO | EP30-12KW PRO |
| MODEL | EP30-8KW PRO | EP30-10KW PRO | EP30-12KW PRO |
| Nominal Battery System Voltage | 48VDC | 48VDC | 48VDC |
| INVERTER OUTPUT | |||
| Continuous output power | 8.0KW | 10.0KW | 12.0KW |
| Surge rating | 24000VA | 30000VA | 36000VA |
| Capable Of Starting Electric Motor | 4HP | 5HP | 6HP |
| Output waveform | Pure sine wave / same as input (bypass mode) | ||
| Inverter Efficiency(Peak) | >88% | ||
| Line mode efficiency | >95% | ||
| Power factor | 1 | ||
| Nominal output voltage RMS | 220V / 230V / 240VAC 卤10% (RMS) | ||
| Output frequency | 50Hz | ||
| Short circuit protection | Yes (1sec after fault) | ||
| Typical transfer time | 10ms(max) | ||
