Description
- The ECO Farm HBP 1800 Series is with a ground breaking 3200Wh/6400Wh BYD LiFePO4 battery pack and a 1000W/2000W/3000W rated pure sine waveAC inverter.Versatile energy storage system backs up in your home and scales, reliable access to power sources at any time. This class-leading powerstation brings you the power to run your entire party, family camping trip, cabin workshops, or even your whole house for a day or two in the event of anunexpected outage.
- Features higher capacities for greater compatibility with more power-hungry devices, and the latest in USB-C Power Delivery capable of charging larger USB devices like laptops.
- Includes pre-installed solar charging optimization module that functions as a maximum power point tracker (MPPT), resulting in up to 40% faster charge times.
- With grade A BYD LiFePO4 lithium cells, known for stability and safety, monitored by a state-of-the-art battery management system that
- prevents over-charge, over-current, and short circuiting.
- Built in Multi safety protection that include short circuit, overload and over-temperture and error code reporting.
- 3200Wh/6400Wh High Capacity;
- 4000+ Charge Cycles;
- BYD LiFePO4 battery pack;
- 2 USB ports;
- Bult-in MPPT 60A solar charge controller.
| AC model | |||
| Inverter model | 1012 60A | 2024 60A | 3024 60A |
| Rated power | 1000W | 2000W | 3000W |
| AC input voltage | 230Vac ±5% | ||
| Nominal input frequency | 50Hz / 60Hz (Auto detection) | ||
| Transfer time | 10ms typical (UPS, VDE); 20ms typical (APL) | ||
| Inverter model | |||
| Output voltage wavefrom | Pure sine wave | ||
| Output voltage regulation | 230Vac±5% | ||
| Output frequency | 50Hz or 60Hz (±0.2Hz) | ||
| Peak efficiency | 90% | ||
| Nominal DC input voltage | 12Vdc (±0.3) | 24Vdc (±0.3) | 24Vdc (±0.3) |
| Low DC warning voltage | 10.7Vdc | 21.4Vdc | 21.4Vdc |
| Low DC warning return voltage | 10.6Vdc | 21.2Vdc | 21.2Vdc |
| Low DC cut-off voltage | 10.2Vdc | 20.4Vdc | 20.4Vdc |
| High DC recovery voltage | 14.5V | 29Vdc | 29Vdc |
| High DC cut-off voltage | 15.0V | 30Vdc | 30Vdc |
| Standby Consumption | < 25W | < 25W | < 25W |
| Utility charging model | |||
| Charging current @ Nominal input voltage | 10/20A (±4A) | 10/20A (±4A) | 20A/30A (±4A) |
| Charging algorithm | 4-step (Li) | ||
| Solar charging model | |||
| Rated power | 900W | 1800W | 1800W |
| PV max charging current | 60A (±3A) | 60A (±3A) | 60A (±3A) |
| Combined charging current | 70A (±4A) | 70A (±4A) | 80A (±4A) |
| Max efficiency | 98.0% max | ||
| PV array open circuit voltage | 75V | 100Vdc | 100Vdc |
| PV Array MPPT Voltage Range | 15~75V | 30~80Vdc | 30~80Vdc |
| Output | |||
| USB (5V 2.4A) | DC output*2pcs | ||
| USB (12V DC5.5, 3A) | DC output*1pc | ||
| AC output | 4pcs | ||
| Battery | |||
| Nominal energy | 3200Wh | 6400Wh | |
| Cycle Life | 4000 + | ||
| Nominal voltage | 12.8V | 25.6V | |
| Normal charge voltage | 14.6V | 29.2V | |
| Standard charging and discharge current | 50.0A | 50.0A | |
| Maximum continuous charging and discharge current | 100.0A | 100.0A | |
| End of discharge voltage | 10.0V | 20.0V | |
| Operation temperature | 0~45℃ | 0~45℃ | |
| -10~60℃ | -10~60℃ | ||
