Description
- MPPT (Maximum Power Point Tracking) solar charge controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array. Each charge controller allows customized battery recharging.
- LCD display, easy to operate on LCD screen
- Multi stage charging (3-stage charging , parallel charging and equalized charging function)
- BTS - Battery remote temperature sensor terminal
- Enable to charge Li-thium, Gel , lead-acid battery
- With RS485 & USB communication port
- Protection: PV array short circuit, PV reverse polarity, Battery reverse polarity, Over charging, Output short circuit
| MODEL | PC16-2015A | PC16-3015A | PC16-4015A |
| Nominal Battery System Voltage | 12VDC / 24VDC (Auto Detection) | ||
| CONTROLLER INPUT | |||
| PV Open Circuit Voltage | 100VDC@12V / 145VDC @24V | ||
| PV Array MPPT Voltage Range | 16VDC~100VDC@12VDC/32VDC~130VDC@24VDC | ||
| Max PV Input Power(12V) | 300W | 450W | 600W |
| Max PV Input Power(24V) | 600W | 900W | 1200W |
| Environmental Rating | Indoor | ||
| Operation Temperature Range | 0℃ ~ 55℃ | ||
| Loading (20GP/40GP/40HQ) | 2500pcs / 5000pcs / 5800pcs | ||
