Description
- PH3000 series energy storage inverter has capacity of 3KW and 4KW, it is multi-functional, combining functions of inverter, On-Grid, MPPT solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
- Smart LCD setting(Working modes, Charge Current, Charge Voltage, etc.)
- MPPT efficiency max 98%
- Combining solar system, AC utility, and battery power source to supply continuous power
- Multiple operations: basic Grid-tie, Off-Grid, Grid-Interactive Parallel operation with up to 3 units
- Parallel operation with up to 3 units
- Support CAN, RS485 monitoring function
| MODEL | PH30-3048 | PH30-4048 |
| Nominal Battery System Voltage | 48VDC | |
| INVERTER OUTPUT | ||
| Rated capacity | 3750VA | 5000VA |
| Rated output power | 3000W | 4000W |
| Rated output voltage and frequency | 230Vac / 50Hz or 60Hz | |
| Rated output current | 13A | 17.4A |
| Output voltage precision | 230Vac ± 1% | |
| Output frequency precision | 50Hz ± 0.1% | |
| Communication terminal | RS485 / CAN bus | |
| Operation Temperature Range | 0℃～ +50℃ | |
| Environmental Protection Rating | Indoor(IP20) | |
| Ambient humidity | 0~90% relative humididity (non-condensing) | |
| Altitude | ≤3000m | |
