ECO Farm quantum board uses top quality LED Samsung LM561C/LM301B chips, and 120 watts and 240 watts are optional.
- High-efficiency white light quantum boards
- Full-spectrum white and 660nm red (optional): good for all the growth stage of plants
- Backside use aviation aluminum sheet, Better effective and fast cooling
- Keep the balance of the PAR/Lumen output and coverage.
- The dimmer knob is featured to control the light spectrum's intensity from 0% - 100%.
- ECO Farm LED grow light helps to get 50% higher yield harvest performance and save lots of costs.
The quantum board normally have interfaces in two side, but if you have other requirements, we could also offer the interfaces in four sides that will help you to DIY the products freely.
Any requests, pls feel free to contact us.
120W Samsung LM561C Full-spectrum White Led Grow Light
| Lamp Beads Power |
0.5W |
Number of beads |
288 |
| Size |
195*300*10mm |
Lamp Power(Theoretical) |
150W±10% |
| Net Weight |
1KG |
PPFD |
1327 |
| Input Voltage |
100-277V |
PF |
0.99 |
| Working Current |
630mA |
Lifespan |
50,000hrs |
| Work Frequency |
50-60hz |
PPF |
2.14μmol/s/W |
| Work Temperature |
-20°C~40°C |
Irradiation Area |
0.5㎡/30CM |
| Inner Box Packaging |
365*235*100mm |
Gross weight |
2.3KG/1PC |
| Outer Box Packaging |
490*380*430mm |
Gross weight |
19KG/8PCS |
120W Samsung LM561C Full-spectrum White&660nm Red Led Grow Light
| Lamp Beads Power |
0.5W |
Number of beads |
288 |
| Size |
195*300*10mm |
Lamp Power(Theoretical) |
150W±10% |
| Net Weight |
1KG |
PPFD |
1260 |
| Input Voltage |
100-277V |
PF |
0.99 |
| Working Current |
630mA |
Lifespan |
50,000hrs |
| Work Frequency |
50-60hz |
PPF |
2.04μmol/s/W |
| Work Temperature |
-20°C~40°C |
Irradiation Area |
0.5㎡/30CM |
| Inner Box Packaging |
365*235*100mm |
Gross weight |
2.3KG/1PC |
| Outer Box Packaging |
490*380*430mm |
Gross weight |
19KG/8PCS |
240W Samsung LM561C Full-spectrum White Led Grow Light
| Lamp Beads Power |
0.5W |
Number of beads |
576 |
| Size |
195*600*10mm |
Lamp Power(Theoretical) |
240W±10% |
| Net Weight |
2KG |
PPFD |
1425 |
| Input Voltage |
100-277V |
PF |
0.99 |
| Working Current |
630mA |
Lifespan |
50,000hrs |
| Work Frequency |
50-60hz |
PPF |
2.26μmol/s/W |
| Work Temperature |
-20°C~40°C |
Irradiation Area |
0.9㎡/30CM |
| Inner Box Packaging |
655*235*100mm |
Gross weight |
4.1KG/PC |
| Outer Box Packaging |
675*255*425mm |
Gross weight |
17KG/4PCS |
240W Samsung LM561C Full-spectrum White &660nm Red Led Grow Light
| Lamp Beads Power |
0.5W |
Number of beads |
576 |
| Size |
195*600*10mm |
Lamp Power(Theoretical) |
240W±10% |
| Net Weight |
2KG |
PPFD |
1426 |
| Input Voltage |
100-277V |
PF |
0.99 |
| Working Current |
630mA |
Lifespan |
50,000hrs |
| Work Frequency |
50-60hz |
PPF |
2.18μmol/s/W |
| Work Temperature |
-20°C~40°C |
Irradiation Area |
0.9㎡/30CM |
| Inner Box Packaging |
655*235*100mm |
Gross weight |
4.1KG/PC |
| Outer Box Packaging |
675*255*425mm |
Gross weight |
17KG/4PCS |
120W Samsung LM301B Full-spectrum White Led Grow Light
| Lamp Beads Power |
0.5W |
Number of beads |
288 |
| Size |
195*300*10mm |
Lamp Power(Theoretical) |
150W±10% |
| Net Weight |
1KG |
PPFD |
1337 |
| Input Voltage |
100-277V |
PF |
0.99 |
| Working Current |
630mA |
Lifespan |
50,000hrs |
| Work Frequency |
50-60hz |
PPF |
2.11μmol/s/W |
| Work Temperature |
-20°C~40°C |
Irradiation Area |
0.5㎡/30CM |
| Inner Box Packaging |
365*235*100mm |
Gross weight |
2.3KG/PC |
| Outer Box Packaging |
490*380*430mm |
Gross weight |
19KG/8PCS |
120W Samsung LM301B Full-spectrum White&660nm Red Led Grow Lights
| Lamp Beads Power |
0.5W |
Number of beads |
288 |
| Size |
195*300*10mm |
Lamp Power(Theoretical) |
150W±10% |
| Net Weight |
1KG |
PPFD |
1273 |
| Input Voltage |
100-277V |
PF |
0.99 |
| Working Current |
630mA |
Lifespan |
50,000hrs |
| Work Frequency |
50-60hz |
PPF |
2.18μmol/s/W |
| Work Temperature |
-20°C~40°C |
Irradiation Area |
0.5㎡/30CM |
| Inner Box Packaging |
365*235*100mm |
Gross weight |
2.3KG/PC |
| Outer Box Packaging |
490*380*430mm |
Gross weight |
19KG/8PCS |
